Liv Lurra
Details
Feel more connected to the trail with the all-new Lurra. Built for charging up singletrack climbs and diving into fast, flowy descents, this hardtail trail bike is simplicity at its best.
Key Performance Factors:
Optimal Trail Design
Lightweight ALUXX SL-grade aluminum hardtail frame with a steep seat tube angle optimizes your input when powering up climbs and hammering on the flats, resulting in greater efficiency and speed. And a 66-degree head tube angle offers confidence on steep
Boosted Confidence
Take on technical terrain with the 130mm of plush front suspension, high-volume tubeless tires offering extreme traction on roots, rocks and ruts, and a dropper seatpost allowing you to get low and ride with control.
Adventure-Ready
Equipped with mounts for 2 water bottle cages and a small gear bag on the underside of the top tube for extra tools and snacks. Internal cable routing keeps the important stuff tidy and protected, so you can stay focused on the ride ahead.
Wheel Sizing:
Size X-Small - Small: 27.5-inch
Size Small - Medium 29-inch
| Frame Size | X-Small | Small | Small | Medium |
|---|---|---|---|---|
| Seat Tube Length (mm) | 360 | 380 | 380 | 410 |
| Seat Post Insertion Depth (mm) | 290 | 290 | 290 | 340 |
| Seat Tube Angle | 76.0° | 76.0° | 76.5° | 76.5° |
| Top Tube Length (mm) | 544 | 564 | 554 | 575 |
| Head Tube Length (mm) | 95 | 105 | 90 | 100 |
| Head Tube Angle | 66.0° | 66.0° | 66.0° | 66.0° |
| Fork Rake (mm) | 44 | 44 | 44 | 44 |
| Trail (mm) | 113.9 | 113.9 | 121.7 | 121.7 |
| Wheelbase (mm) | 1118 | 1140 | 1136 | 1159 |
| Chain Stay Length (mm) | 438 | 438 | 438 | 438 |
| Bottom Bracket Drop (mm) | 60 | 60 | 60 | 60 |
| Stack (mm) | 608 | 617 | 618 | 627 |
| Reach (mm) | 393 | 410 | 406 | 425 |
| Stand Over Height (mm) | 613 | 661 | 661 | 712 |
| Handlebar Width (mm) | 760 | 760 | 760 | 760 |
| Stem Length (mm) | 40 | 40 | 40 | 50 |
| Crank Length (mm) | 165 | 170 | 170 | 170 |
| Wheel Size | 27.5" | 27.5" | 29" | 29" |
| Frame Size | Rider Height (cm) | Rider Height (in) |
|---|---|---|
| X-Small | 150 - 163 | 4'11" - 5'4" |
| Small | 158 - 169 | 5'2" - 5'7" |
| Medium | 164 - 175 | 5'5" - 5'9" |
Specs
| Pedals | Sold Separately |
|---|---|
| Fork | Giant STL 34 RCL, 140mm, 44mm offset, 15x110mm thru-axle, custom tuned |
| Hubs |
[F] Giant MTB alloy, 6-bolt, sealed [R] Giant MTB alloy, 6 bolt, sealed |
| Rims | Giant AM 27.5 or 29, tubeless ready sleeve-joint rim, 30mm IW |
| Stem | Giant Contact SL 35 |
| Chain | KMC X11 |
| Frame | ALUXX SL-grade aluminum, 12x148 thru-axle |
| Tires |
27.5" [F&R] Maxxis Ardent Race, 27.5x2.6, foldable, TR 29" [F] Maxxis Minion DHF, 29x2.5 WT, foldable, EXO/TR [R] Maxxis Aggressor, 29x2.5 WT, foldable, EXO/TR |
| Brakes |
Shimano BR-MT420, hydraulic Shimano RT-26 rotors, [F]180mm, [R]180mm |
| Saddle | Liv Sylvia |
| Spokes | Sapim |
| Crankset | Shimano CUES U6000, 30t |
| Seatpost |
Giant Contact Switch AT adjustable dropper, remote XS, S: 70-100mm travel / 30.9 x 315mm M: 110-140mm travel / 30.9 x 395mm |
| Shifters | Shimano CUES U6000, 1x10 |
| Handlebars | Giant Contact TR35, 20mm rise, 35mm |
| Tape/Grips | Liv Sole-O |
| Brake Levers | Shimano Deore BL-MT401 |
| Bottom Bracket | Shimano, threaded |
| Rear Derailleur | Shimano CUES RD-U6000 |
| Accessories & Extras | 27.5": tubeless prepared, max tire size 2.6", max chainring size 32t 29": tubeless prepared, max tire size 2.5", max chainring size 32t |
| Cassette/Freewheel | Shimano CUES, LinkGlide, 10-speed, 11x48 |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN |
|---|---|---|
| Tyrian Purple / Small / 29-inch | 4711291143708 | 1068006224 |
| Frost Silver / Medium / 29-inch | 4711291145184 | 1068006125 |
| Frost Silver / X-Small / 27.5-inch | 4711291143586 | 1068005123 |
| Tyrian Purple / X-Small / 27.5-inch | 4711291145054 | 1068005223 |
| Tyrian Purple / Medium / 29-inch | 4711291143715 | 1068006225 |
| Frost Silver / Small / 29-inch | 4711291145177 | 1068006124 |
| Frost Silver / Small / 27.5-inch | 4711291143593 | 1068005124 |
